Parameter DEPTH = 1 DEPTH = 2 DEPTH = 3 DEPTH = 4 DEPTH = 5
Threshold 1 –20 dB –20 dB –30 dB –78 dB –78 dB
Threshold 2 –10 dB –10 dB –25 dB –30 dB –30 dB
Ratio 1 1 : 1 1 : 1 1 : 1 1 : 2 1 : 2.6
Ratio 2 2 : 1 2 : 1 1.25 : 1 1.25 : 2 2.5 : 1
Ratio 3 20 : 1 20 : 1 5 : 1 8 : 2 20 : 1
Attack time constant 0.1 msec 0.1 msec 0.1 msec 0.1 msec 0.1 msec
Release time constant 100 msec 1 msec 5 msec 100 msec 100 msec
COMP. output level 0 dB 0 dB 0 dB +12 dB +24 dB
OFF (default), 1, 2, 3, 4, 5Setting Range
Use the compressor to prevent power amplifier overload or to produce more easily heard sound by averaging
the audio level. The number shows the compressor's effectiveness level as shown in the table below, which
can be set by rotating the Parameter setting knob.
• DEPTH = 1 (Peak limiter)
Provides a peak limiter function that protects amplifiers and speakers against damage caused by an
excessive signal input.
This level is suited to speech applications.
• DEPTH = 2 (Peak limiter)
Provides a peak limiter function that protects amplifiers and speakers against damage caused by an
excessive signal input.
This level is suited to musical applications.
• DEPTH = 3 (Sonic normalizer)
Equalizes the sound volume of reproduced BGM among CDs or pieces of music by boosting small sounds
and lowering big sounds, making the entire sound volume uniform.
This level is suited to BGM reproduction.
• DEPTH = 4 (Speech leveler)
Makes paging calls easier to hear by equalizing the difference in speech signal volume that may result from
individual differences in speaker voice volumes or variations in speaker-to-microphone distances.
Since the volume is extensively corrected, the feedback margin narrows, making it liable to occurrences of
feedback. Therefore, special care must be taken when installing microphones and speakers.
This level is suited to microphone speech applications.
• DEPTH = 5 (Speech leveler)
Makes paging calls easier to hear by equalizing the difference in speech signal volume that may result from
individual differences in speaker voice volumes or variations in speaker-to-microphone distances.
This level 5 is more effective than level 4. Since the volume is extensively corrected, the feedback margin
narrows, making it liable to occurrences of feedback. Therefore, special care must be taken when installing
microphones and speakers.
This level is suited to microphone speech applications.
Note: For the compression characteristics diagram, refer to p. 136.
Set the delay function to ON or OFF.
When ON, the delay time setting follows.
• ON: The delay function works.
• OFF: The delay function does not work.
ON, OFF (default)
Setting Range
