Toa A-9120DHM2 - Page 77

77
(C7) Control input terminal status display
(when all are open)
(C7) Control input terminal status display
(when all are closed)
C I N =
- - - - - - - - - - - -
C I N = 1 2 3 4 5 6 7 8 9 A B C
(C5) Control input terminal function display
C - I N I N F 0 1 = N O N E
(C6) Control input terminal status information
C - I N S T A T U S
When STATUS is selected, current control input terminal statuses are displayed on the screen.
(C8) Control output terminal number selection
C - O UT 0 1 - > N O N E
(C9) Control output terminal setting information
C - O U T F U N C T I O N
When FUNCTION is selected, functions assigned to the control output terminals are displayed on the screen.
Displays the function assigned to the control input terminal.
The screen indications represent the following functions:
• NONE: No function is assigned.
• PG TRIG: Paging activation
• LOADSCENE: Scene memory recall
• VOLUP: Volume up
• VOLDOWN: Volume down
• CH ON: Channel ON
• CH MUTE: Channel mute
• EMG MUTE: Emergency mute activation (All output channel mute)
• POWER: Power ON
Status of all control input terminals can be confirmed on the screen, with the terminal Nos. 1 – 12 arranged in
numerical order from left to right.
When closed, the terminal number is indicated by alpha-numerals. Alphabet A represents the terminal number
10, B represents 11, and C represents 12.
An open terminal is indicated by an underscore "_".
Set the control output terminal number to be assigned to the control output function.
To set a terminal number, refer to p. 75 for the flow chart of the control output function setting.
Note: The control output terminal having the function of CH MUTE (Channel mute), EMG MUTE (Emergency
mute, or all output channel mute), or PG OUT (Paging activation) is represented as "NONE" on the
screen.
C-IN01 – 04, C-IN01 – 12 when C-001T is used
Setting Range
