78
(C10) Control output terminal function display
C - O U T I N F 0 1 = N O N E
(C12) Control output terminal status display
(when all are open)
(C12) Control output terminal status display
(when all are closed)
C O U T =
- - - - - - - - - - - -
C O U T = 1 2 3 4 5 6 7 8 9 A B C
(C11) Control output terminal status information
C - O U T S T A T U S
When STATUS is selected, current control output terminal statuses are displayed on the screen.
(C13) Remote control input terminal setting
R E M O T E S E T T I N G
Sets functions assigned to the remote control terminals (REMT VOL1 and REMT VOL2).
(C14) Remote controller type setting
R E M O T E 1 - > V O L U M E
Displays the function assigned to the control output terminal.
The screen indications represent the following functions:
• NONE: No function is assigned.
• POWER: Power ON
• LD SCENE: Scene memory recall
• CH ON: Channel ON
• CH MUTE: Channel mute
• EMG MUTE: Emergency mute activation (All output channel mute)
• PG OUT: Paging activation
Status of all control output terminals can be confirmed on the screen, with the terminal Nos. 1 – 12 arranged in
numerical order from left to right.
When closed, the terminal number is indicated by alpha-numerals. Alphabet A represents the terminal number
10, B represents 11, and C represents 12.
An open terminal is indicated by an underscore "_".
Set the type of remote controller connected to the remote control input terminals.
Use the Left and Right shift keys to move the setting items on the screen.
• OFF: Select this setting when no remote controller is connected.
• VOLUME: Select this setting when a normal variable resistor or variable DC power supply unit is connected.
• ZM-9001: Select this setting when the ZM-9001 is connected. This setting adds 6 control inputs. These
inputs are assigned the functions in the setting screen on p. 83-C43.
• ZM-9002: Select this setting when the ZM-9002 is connected. This setting adds 4 control inputs and 1
remote volume control. These inputs are assigned the functions in the setting screens on p. 83-
C43.
REMOTE 1, REMOTE 2
OFF (default) , VOLUME, ZM-9001, ZM-9002
Setting Range
Remote Volume Terminal Number
Controller type
