2-20
dummyheaddummyhead
SERVICE INFORMATION
FUSE/RELAY JUNCTION BOX 8P CONNECTOR
NMEA INTERFACE WIRE
(Optional part)
POWER TILT
RELAY WIRE
TERMINAL
INTERFACE
6P CONNECTOR
ALTERNATOR
4P CONNECTOR
SWITCH PANEL
WIRE HARNESS
14P CONNECTOR
DLC 4P
INDICATOR PANEL
WIRE HARNESS
6P CONNECTOR
NEUTRAL SWITCH
2P CONNECTOR
STARTER CABLE 1 (+)
HARNESS BAND CLIP
TACH PULSE
2P CONNECTOR
ACG CABLE
STARTER CABLE 1 (+)
FUSE/RELAY JUNCTION BOX
10P CONNECTOR
FUSE/RELAY JUNCTION BOX
23P CONNECTOR
