Loading New Firmware
P/N 7010-0681
4-25
NOTICE
NOTICE
If you selected an incorrect file, an error message displays
at the bottom of the dialog box. Select the correct file.
5. Select the Device tab and set the Device Type as Receiver’s Power
Board. Then click Get from Device for device information
(Figure 4-17).
Figure 4-17. Set Device Type
6. Select the Program tab and set the Capture Method to Soft Break
Capture (recommended) (Figure 4-18).
Figure 4-18. Program Tab Settings
7. Browse for and select the Power board’s RAM file (Figure 4-18).
