Toptech MultiLoad II - TRANSACTION AND BATCH AUTHORIZATION PROCESSES

Chapter 8 – Communication Trace Example
166
Sent:(FPOWERUP) Received:(000)
logmsg_queued bit is set
Modbus:
Fn=0x06, Write 0 to Register 7012
Sent:(R910) Received: (00091000010515153200REGAINED COMMUNICATION WITH HOST.)
host_up bit is clear
Modbus:
Fn=0x03, Read Registers 2600 ... 2685
Sent:(FHOSTUP) Received: (000)
Modbus:
Fn=0x06, Write 0 to Register 7013
8.2 TRANSACTION AUTHORIZATION
8.2.1 PROCESS DRIVER CARD IN
Reset terminal screen.
Sent:(T_R) Received: (000)
Modbus:
Fn=0x06, Write 0 to Register 7017
Wait for card in by watching the CARD_STATUS character
Sent:(Q) Received: (000C218)
Sent:(Q) Received: (000C218)
...(some time later)...
Sent:(Q) Received: (041C218)
Modbus:
Fn=0x03, Read Register 7001 -> 0
Fn=0x03, Read Register 7001 -> 0
...(some time later)...
Fn=0x03, Read Register 7001 -> 1
Get the card number
Sent:(R962) Received: (0419620=01=0000000=00004504=01)
Modbus:
Fn=0x03, Read Registers 2900 … 2979
Prompt for Driver PIN
Sent:(T_H_K_>Enter Pin: _!_L04_E) Received: (041)
Modbus:
Use Extended Services Register
Wait for driver input_done bit to be set
Sent:(Q) Received: (041C618)
