Toptech MultiLoad II - STATUS AND ALARM REQUESTS

Chapter 6 – Meter Commands
29
6.10 REQUEST STATUS & PRESET ALARMS:
MRSpppxxxxyyyyzzzzaaaa => RSppp… (Requested parameters as listed below).
Where:
ppp = The specified zero-based preset or load arm number (000-011).
Xxxx = Optional response configuration bits #0 in hexadecimal as:
union
{
unsigned int value;
struct
{
unsigned int preset_state:1;
unsigned int preset_status_0:1;
unsigned int preset_alarms:1;
unsigned int volume_preset_whole:1;
unsigned int batch_gross_del_whole:1;
unsigned int batch_net_del_whole:1;
unsigned int batch_temp_tenths:1;
unsigned int batch_pressure_tenths:1;
unsigned int batch_gravity:1;
unsigned int gross_flow_rate:1;
unsigned int component_batch_gross_del_whole:1;
unsigned int component_batch_net_del_whole:1;
unsigned int component_batch_temp_tenths:1;
unsigned int component_batch_pressure_tenths:1;
unsigned int component_batch_gravity:1;
unsigned int additive_batch_gross_del_thous:1;
} flags;
} query_0; (default value 0x965f.)
