Toptech MultiLoad II User Manual

Chapter 7 – Register Operations
13
4
ddddd = Gravity or Density or Relative Density
eeeeee = average pressure in hundredths
Modbus:
Read/Write Register=7810, Len=1, 16-Bit Integer (ppp)
Read/Write Register=7811, Len=1, 16-Bit Integer (tt)
Read/Write Register=7812, Len=6, Characters (cccccc)
Read/Write Register=7818, Len=2, 32-Bit Integer (ggggggggg)
Read/Write Register=7820, Len=2, 32-Bit Integer (nnnnnnnnn)
Read/Write Register=7822, Len=1, 16-Bit Integer (ttttt)
Read/Write Register=7823, Len=1, 16-Bit Integer (dddd)
Read/Write Register=7824, Len=1, 16-Bit Integer (mm)
Read/Write Register=7825, Len=1, 16-Bit Integer (rrrr)
Read/Write Register=7826, Len=1, 16-Bit Integer (sssss)
Read/Write Register=7827, Len=1, 16-Bit Integer (tttt)
Read/Write Register=7828, Len=1, 16-Bit Integer (uuuuu)
Read/Write Register=7829, Len=1, 16-Bit Integer (vvvvv)
Read/Write Register=7830, Len=1, 16-Bit Integer (wwww)
Read/Write Register=7831, Len=1, 16-Bit Integer (xxxxxxx)
Read/Write Register=7832, Len=1, 16-Bit Integer (zzzzzzzzz)
Read/Write Register=7833, Len=1, 16-Bit Integer (aaaaa)
Read/Write Register=7834, Len=1, 16-Bit Integer (bbbbb)
7.2 SPECIAL PURPOSE REGISTERS
7.2.1 000 – MULTILOAD FIRMWARE VERSION
R000 => 0?0sssssssssssssssssss
Where:
sssssssssssssssssss = Firmware Identification
000MultiLoad II v3.31.xx Jan xx 2011
000MultiLoad II v4.31.xx Jan xx 2011
000MultiLoad 1Arm v3.31.xx Jan xx 2011 (discontinued)
000MultiLoad 1Arm v4.31.xx Jan xx 2011 (discontinued)
000MultiLoad Mobl v3.31.xx Jan xx 2011
000MultiLoad Mobl v4.31.xx Jan xx 2011
000MultiLoad SMP v3.31.xx Jan xx 2011
000MultiLoad SMP v4.31.xx Jan xx 2011
Modbus: Read Only Register=000, Len=35, Characters (sssssssssssssssssss)
7.2.2 001 – DATE AND TIME
R001 => 0?0001YYMMDDHHMMSS
U001YYMMDDHHMMSS => 0?0
Where:
YY = Year (00-99).
MM = Month (01-12)
