Chapter 8 – Communication Trace Example

168

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000)

Sent:(R112001) Received:

(0001120010000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000)

Sent:(R112002) Received:

(0001120020000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000)

Sent:(R112003) Received:

(0001120030000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000)

Sent:(R112004) Received:

(0001120040000000000000000000000000000000000000000000000000000000000000000000000000000000

00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

0000)

Modbus:

Fn=0x03, Read Registers 3000 … 3006 (Preset Gross Totalizers)

Fn=0x03, Read Registers 3144 … 3191 (Component Gross Totalizers)

Fn=0x03, Read Registers 3336 … 3432 (Additive Gross Totalizers)

Etc…

8.3 BATCH AUTHORIZATION

8.3.1 AUTHORIZE A BATCH ON MULTILOAD

Checking status found a preset authorization request for a preset.

Sent:(Q) Received: (0a1CA1A)

Modbus:

Fn=0x03, Read Register 7000 -> a

Prompt driver for batch information.

Display available product names

Sent:(T_H_K_Y! 1. Regular Unlead_Y” 2. Premium Unlead) Received: (0a1)

Modbus:

Use Extended Services Register

Prompt for product name

Sent:(T_H_>Enter Preset #01 Product Code: _@ _L02_E) Received: (0a1)

Modbus:

Use Extended Services Register

Wait for driver input done
