Toptech MultiLoad II User Manual

Chapter 6 – Meter Commands
28
6.8 PRESET MESSAGE:
MPMpppssssssssssddddddddddddddddddddddddddddddddddddddd
Where:
ppp = The specified zero-based preset or load arm number (000-011).
Ssssssssss = 10 Character Message.
Ddddddddddddddddddddddddddddddddddddddd = 39 Character Detail Message.
Displays a message for the particular preset. A detail message will be displayed when the preset is selected.
Driver and acknowledge and clear the message by pressing CLR key.
Modbus:
Only supported through Modbus Extended Services Registers.
6.9 PROVING TRANSACTION MODE:
MPTx
When:
x = Mode Status 0 = Off, 1 = On. Default Off when transaction is authorized.
Command is used to indicate when a card in is done with a proving card and meter proving may be done during
this transaction.
Modbus:
Write Only Register=7081, Len=1, 16-Bit Integer (x)
