Chapter 6 – Meter Commands
49
xxxx= component status #2 in hexadecimal as:
union
{
unsigned int value;
struct
{
unsigned char unused2_0:1; // future use
unsigned char unused2_1:1; // future use
unsigned char unused2_2:1; // future use
unsigned char unused2_3:1; // future use
unsigned char unused2_4:1; // future use
unsigned char unused2_5:1; // future use
unsigned char unused2_6:1; // future use
unsigned char unused2_7:1; // future use
unsigned char unused2_8:1; // future use
unsigned char unused2_9:1; // future use
unsigned char unused2_10:1; // future use
unsigned char unused2_11:1; // future use
unsigned char unused2_12:1; // future use
unsigned char unused2_13:1; // future use
unsigned char unused2_14:1; // future use
unsigned char unused2_15:1; // future use
} flags:
} component_status_2;
Modbus:
Supported through Modbus Extended Services Registers.
