12: PNEUMATIC SCHEMATICS
©Tormach® 2024
Specifications subject to change without notice.
Page 109 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version
0324A)
For the most recent version, see tormach.com/support
12.2 PNEUMATIC SYSTEM PARTS LIST
ID Description Quantity
1 Infeed Cylinder 1
2 Speed Controller 3
3 Male Elbow 6
4 Silencer 2
5 Compact Cylinder 1
6 Compact Cylinder 1
7 Pressure Regulator 1
8 Pressure Gauge 2
9 Fitting 1
10 Regulator 1
11 Fitting 1
12 Fitting 1
13 Fitting 1
14 Solenoid Valve 5
15 Silencer 7
16 Manifold 1
17 Fitting 4
18 Manifold 1
19 Lifting Cylinder 1
