10: TROUBLESHOOTING
©Tormach® 2024
Specifications subject to change without notice.
Page 71 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version
0324A)
For the most recent version, see tormach.com/support
10. Open the blade cover, as shown in the following image.
Figure 10-8: Blade cover opened.
11. Identify the tensioner on the top of the saw head.
Figure 10-9: Tensioner on top of the saw head.
12. Verify that the blade tension is set correctly.
13. Power on the bandsaw.
a. Rotate the Emergency Stop button on the operator panel one-quarter turn clockwise to release it.
b. Turn the Main Disconnect switch to ON.
Mains power is connected to the machine.
