ServiceandRepairs
CAUTION
Donotinstallorworkonthecuttingdecksorliftarmswiththe
enginerunning.
Alwaysshutofftheengineandremovethekeyfromthekeyswitch
beforeworkingonthecuttingdecksorliftarms.
BladeSpindleAssembly
g195110
Figure228
1.Hydraulicdeckmotor5.Anti-scalpcup
9.Spindleplate
2.Cuttingdeck6.Cuttingblade10.Flangenut(6each)
3.Stud(6each)7.Spindleassembly11.Flatwasher(2each)
4.Bladebolt
8.O-ring12.Socket-headscrew(2each)
Groundsmaster
®
4300-D
Page7–7
CuttingDeck:ServiceandRepairs
16226SLRevC
