ServicingtheBladeSpindle
g195112
Figure230
1.Spindlenut
7.Bearing
2.Spindleplug8.Spindlehousing
3.Oilseal(2each)9.Shaftspacer
4.Bearing
10.Spindleshaft
5.Spacerset(2piece)11.Greasetting(2each)
6.Spacerring
12.Largesnapring
g189007
Figure231
1.Bearing4.Innerbearingspacer
2.Spacerring5.Outerbearingspacer
3.Largesnapring
CuttingDeck:ServiceandRepairs
Page7–10
Groundsmaster
®
4300-D
16226SLRevC
