Toro Groundsmaster 4300-D Service Manual

JackingInstructions
CAUTION
Failingtoproperlysupportthemachinewithappropriatejackstands
cancausethemachinetomoveorfallandcanresultinpersonal
injury.
Whenchangingtheattachments,tires,orperformingotherservices,
dothefollowingsteps:
•Usecorrectblocks,hoists,andjackstoraiseandsupportthe
machine.
•Parkthemachineonasolidlevelsurface,suchasaconcrete
oor.
•Beforeyouliftthemachine,removealltheattachmentsthatmay
interferewiththesafeandcorrectliftofthemachine.
•Alwaysblockthewheelswithchocks.
•Useappropriatejackstandstosupporttheraisedmachine.
•Donotusethecuttingdeckorimplementasajackingpoint.
RaisingtheFrontoftheMachine
g186590
Figure2
1.Frontwheel2.Frontjackingpoint
1.Settheparkingbrakeandblockthe2rearwheelswithchockstoprevent
themachinefrommoving.
2.Positionthejackundertherectangularpadonthefrontaxletube,justtothe
insideofthefrontwheel(Figure2).
3.Useajacktoraisethefrontofthemachine.
4.Positionjackstandsundertheframeasclosetothewheelaspossibleto
supportthemachine.
Safety:JackingInstructions
Page1–6
Groundsmaster
®
4300-D
16226SLRevC
