Toshiba E-STUDIO520 Network Administration Guide

1. Easy Setup Flow
Network Administration Guide — Setup Flow for Fax Features 39
Setup Flow for Fax Features
This section describes the minimum setup flow to configure this equipment for Fax fea-
tures.
Setup Flow for Network-Fax
Using the N/W-Fax driver, users can send a document to this equipment as a print job.
The equipment then sends the job to the fax numbers (or Email addresses) specified by
the user through the Public Switched Telephone Network or the Internet.
To send a fax through the Public Switched Telephone Network, users must configure
the equipment accordingly.
When sending an Internet Fax, the equipment sends the document to the SMTP server
and transfers it to the Internet. (A DNS server is required for the SMTP server to trans-
mit the document into the Internet.)
System Requirements
The N/W-Fax driver is available for following computers:
• Display Resolution
1024 x 768 dots or more
• Display Color
High Color (16bit) or higher is recommended
•CPU
Pentium 133 MHz minimum (Pentium 266 MHz or faster recommended)
• The fax transmission using the N/W-Fax driver is available only when the Printer
Kit or Printer/Scanner Kit is installed in addition to optional Fax unit.
• The Internet Fax transmission using the N/W-Fax driver is available only when
the Printer Kit and Scanner Kit are installed, or when the Printer/Scanner Kit is
installed.
Connecting to Internet
Printing a document
using N/W-Fax driver
Send a document as
Internet Fax to the Internet
via SMTP server
Send a document as
fax document via
Public Switched Telephone
network
Internet
G3 Facsimile or
Internet Fax Device
Windows 98
Windows Me
Windows NT 4.0
Windows 2000
Windows XP
Windows Server 2003
SMTP Server
