4 Replacement Procedures 4.8 Display assembly
4-28 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
12. Remove the following screws to separate the display from the middle frame.
? M2.5?6B FLAT BIND x4
Figure 4-19 Removing the display
M2.5x6B FLAT BIND
Display
Middle frame
