4.24 North bridge (and GPU) heat sink/CPU heat sink/Fan/CPU 4 Replacement Procedures
10. Remove the fan hood.
11. Remove the following screws and separate the CPU heat sink and fan.
• M2.5×4B FLAT HEAD screw ×2
Fan
M2.5×4B FLAT HEAD
M2.5×4B FLAT HEAD
CPU heat sink
Fan hood
Figure 4-41 Removing the fan
