Toshiba Tosvert VF-S15 User Manual

E6582175
A-13
1
M3.5 screw
Grounding terminal
(M4 screw)
Shorting-bar
For EMC plate
Grounding terminal
(M4 screw)
Grounding terminal
(M5 screw)
1.3.3 Power circuit and control circuit terminal blocks
1) Power circuit terminal
In case of the crimp-style terminal, cover the crimp-style terminal with insulating tube, or use the crimp-
style terminal with insulation sleeve.
Refer to section 2.3.1 for details about terminal functions.
Screw Size
Crimp-style
terminal
Note1
)
Tightening torque
M3.5
xxx
– 3.5
1.0 N
m 8.9 lbin
M4
xxx
– 4
1.4 N
m 12.4 lbin
M5
xxx
– 5
2.4 N
m 20.8 lbin
M6
xxx
– 6
4.5 N
m 40.0 lbin
M4 (grounding terminal)
xxx
– 4
1.4 N
m 12.4 lbin
M5 (grounding terminal)
xxx
– 5
2.8 N
m 24.8 lbin
Note1) xxx means wire sizes. For the wire sizes, refer to the table in section 10.1
VFS15-2004PM-W1 to 2007PM-W1
Note1) Bend the clips on the wiring port of the terminal cover to connect the PB, PO, PA/+, and PC/- terminals.
Note2) Be careful to insert all wires into the cage of terminal block.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
