Toshiba Tosvert VF-S15

E6582175
K-12
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0315 Factory specific
coefficient 3M
- - - - * 3

0316 PWM carrier
frequency control
mode selection
- - 0: Carrier frequency without reduction 1
(240V
class)
5
(500V
class)
6.18
1: Carrier frequency with automatic
reduction
2: Carrier frequency without reduction
Support for 500V models pattern 1
3: Carrier frequency with automatic
reduction
Support for 500V models pattern 1
4: Carrier frequency without reduction
Support for 500V models pattern 2
5: Carrier frequency with automatic
reduction.
Support for 500V models pattern 2

0317 Synchronized
deceleration time
(time elapsed
between start of
deceleration to stop)
s 0.1/0.1 0.0-3600 (360.0) 2.0 6.19.2

0318 Synchronized
acceleration time
(time elapsed
between start of
acceleration to
achievement of
specified speed)
s 0.1/0.1 0.0-3600 (360.0) 2.0

0319 Regenerative
over-excitation
upper limit
% 1/1 100-160 *1 6.19.5

0320 Droop gain % 0.1/0.1 0.0-100.0 0.0 6.20

0323 Droop insensitive
torque band
% 1/1 0-100 10

0324 Droop output filter - 0.1/0.1 0.1-200.0 100.0

0325 Brake releasing
waiting time
s 0.01/0.01 0.00-2.50 0.00 6.22.1

0326 Brake releasing
small current
detection level
%
(A)
1/1 0-100 *12 0

0327 Factory specific
coefficient 3C
- - - -
* 3

0328 Light-load high-
speed operation
selection
- - 0:Disabled
1:High-speed operation speed set
automatically (Power running at F
command: Increase)
2:High-speed operation speed set
automatically (Power running at R
command: Increase)
3:High-speed operation speed set
with f330 (Power running at F
command: Increase)
4:High-speed operation speed set
with f330 (Power running at R
command: Increase)
0 6.21
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
*12: When f701=1, adjustment range is 100%=rated current, or 100%=200V(240V class)/ 400V(500V class).
