User Guide 158
Configuring MAC VLAN MAC VLAN Configuration
1) Enter the MAC address of the device, give it a description, and enter the VLAN ID to
bind it to the VLAN.
MAC Address Enter the MAC address of the device in the format of 00-00-00-00-00-01.
Description Give a MAC address description for identification with up to 8 characters.
VLAN ID/Name Enter the ID number or name of the 802.1Q VLAN that will be bound to the MAC
VLAN..
2) Click Create.
Note:
One MAC address can be bound to only one VLAN.
2.1.3 Enabling MAC VLAN for the Port
By default, MAC VLAN is disabled on all ports. You need to enable MAC VLAN for your
desired ports manually.
Choose the menu L2 FEATURES > VLAN > MAC VLAN to load the following page.
Figure 2-2 Enabling MAC VLAN for the Port
In the Port Enable section, select the desired ports to enable MAC VLAN, and click Apply.
Note:
The member port of an LAG (Link Aggregation Group) follows the configuration of the LAG and not its
own. The configurations of the port can take effect only after it leaves the LAG.
