Configuring Layer 2 Multicast Configuration Examples
User Guide 275
Gi1/0/5, Gi1/0/6, Gi1/0/7, Gi1/0/8,
...
10 vlan10 active Gi1/0/1, Gi1/0/2, Gi1/0/3, Gi1/0/4
Show status of IGMP Snooping globally, on the ports and in the VLAN:
Switch(config)#show ip igmp snooping
IGMP Snooping :Enable
IGMP Version :V3
Header Validation :Disable
Global Authentication Accounting :Disable
Enable Port : Gi1/0/1-4
Enable VLAN:10
7.2 Example for Configuring MVR
7.2.1 Network Requirements
Host B, Host C and Host D are in three different VLANs of the switch. All of them want to
receive multicast streams sent to multicast group 225.1.1.1.
7.2.2 Network Topology
As shown in the following network topology, Host B, Host C and Host D are connected to
port 1/0/1, port 1/0/2 and port 1/0/3 respectively. Port 1/0/1, port 1/0/2 and port 1/0/3
belong to VLAN 10, VLAN 20 and VLAN 30 respectively. Port 1/0/4 is connected to the
multicast network in the upper layer network.
