User Guide 556
Configuring 802.1x 802.1x Configuration
2
802.1x Configuration
To complete the 802.1x configuration, follow these steps:
1) Configure the RADIUS server.
2) Configure 802.1x globally.
3) Configure 802.1x on ports.
In addition, you can view the authenticator state.
Configuration Guidelines
802.1x authentication and Port Security cannot be enabled at the same time. Before
enabling 802.1x authentication, make sure that Port Security is disabled.
2.1 Using the GUI
2.1.1 Configuring the RADIUS Server
Configure the parameters of RADIUS sever and configure the RADIUS server group.
â– Adding the RADIUS Server
Choose the menu SECURITY > AAA > RADIUS Config and click to load the
following page.
Figure 2-1 Adding RADIUS Server
Follow these steps to add a RADIUS server:
