Configuring LLDP Viewing LLDP Settings
User Guide 381
Total Age-outs Displays the latest number of neighbors that have aged out on the local device.
3) In the Neighbors Statistics section, view the statistics of the corresponding port.
Transmit Total Displays the total number of the LLDP packets sent via the port.
Receive Total Displays the total number of the LLDP packets received via the port.
Discards Displays the total number of the LLDP packets discarded by the port.
Errors Displays the total number of the error LLDP packets received via the port.
Age-outs Displays the number of the aged out neighbors that are connected to the port.
TLV Discards Displays the total number of the TLVs discarded by the port when receiving LLDP
packets.
TLV Unknowns Displays the total number of the unknown TLVs included in the received LLDP
packets.
4.2 Using CLI
â– Viewing the Local Info
show lldp local-information interface { fastEthernet
port
| gigabitEthernet
port
| ten-gigabitEthernet
port
}
View the LLDP details of a specific port or all the ports on the local device.
â– Viewing the Neighbor Info
show lldp neighbor-information interface { fastEthernet
port
| gigabitEthernet
port
| ten-
gigabitEthernet
port
}
Display the information of the neighbor device which is connected to the port.
â– Viewing LLDP Statistics
show lldp traffic interface { fastEthernet
port
| gigabitEthernet
port
| ten-gigabitEthernet
port
}
View the statistics of the corresponding port on the local device.
