Managing System PoE Configurations (Only for Certain Devices)
User Guide 71
Step 8 show power inline
Verify the global PoE information of the system.
Step 9 show power inline configuration interface [ fastEthernet { port | port-list } | gigabitEthernet {
port | port-list } | ten-gigabitEthernet { port | port-list }]
Verify the PoE configuration of the corresponding port.
port : Specify the Ethernet port number, for example 1/0/1.
port-list : Specify the list of Ethernet ports, in the format of 1/0/1-3, 1/0/5.
Step 10 show power inline information interface [ fastEthernet { port | port-list } | gigabitEthernet {
port | port-list } | ten-gigabitEthernet { port | port-list } ]
Verify the real-time PoE status of the corresponding port.
port : Specify the Ethernet port number, for example 1/0/1.
port-list : Specify the list of Ethernet ports, in the format of 1/0/1-3, 1/0/5.
Step 11 end
Return to privileged EXEC mode.
Step 12 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to set the system power limit as 160 W. Set the priority
as middle and set the power limit as class3 for the port 1/0/5.
Switch#configure
Switch(config)#power inline consumption 160
Switch(config)#interface gigabitEthernet 1/0/5
Switch(config-if)#power inline supply enable
Switch(config-if)#power inline priority middle
Switch(config-if)#power inline consumption class3
Switch(config-if)#show power inline
System Power Limit: 160.0w
System Power Consumption: 0.0w
System Power Remain: 160.0w
Switch(config-if)#show power inline configuration interface gigabitEthernet 1/0/5
Interface PoE-Status PoE-Prio Power-Limit(w) Time-Range PoE-Profile
---------- ---------- ---------- ------------ ------------- ----------------
Gi1/0/5 Enable Middle Class3 No Limit None
