Chapter 8 Installing Tracer Summit system software
108 BMTX-SVN01C-EN
Network Connections icon. The Network and Dial-up Connections
window appears.
3. Double-click the connection name that corresponds to the Ethernet
adapter. The adapter status window appears.
4. Click the Properties button. The adapter Properties window appears.
5. Double-click the Internet Protocol (TCP/IP) in the component list. The
Internet Protocol (TCP/IP) Properties dialog box appears.
6. Click Use the following IP address. Enter the required IP address,
subnet mask, and default gateway information. (This information can
be obtained from the customer’s Information Systems group.)
7. Click OK to close the Internet Protocol (TCP/IP) Properties dialog
box. Click OK to close the adapter Properties dialog box. Close the
Local Area Connections Status dialog box.
8. Restart the computer.
Verifying network adapter status and protocol
for Windows XP Professional or Windows 2000
Professional
1. From the Windows Start menu, select Settings. Then, select Control
Panel.
2. For Windows 2000 Professional, double-click the Network and Dial-
up Connections icon. For Windows XP Professional, double-click the
Network Connections icon. The corresponding window appears.
3. Double-click the connection name that corresponds to the Ethernet or
ARCNET adapter. Verify the adapter settings:
• For dedicated Ethernet and ARCNET, Tracer Summit automati-
cally installs support. Verify that the adapter is not bound to any
other protocols.
• For Ethernet adapters on a shared network, verify that the TCP/
IP protocol is installed. Information Systems personnel who are
in charge of the workstation should verify any other protocols
selected.
4. Click the OK button. If you made any changes, you will need to
restart the PC when prompted.
Note:
After you have set up the network adapter, you need to verify
the adapter status to make sure there are no conflicts with
other IRQ or I/O addresses. Windows XP Professional or Win-
dows 2000 Professional systems automatically check for
resource conflicts when you are installing new adapters.
