Chapter 6 UCMs supported by Tracer Summit systems
60 BMTX-SVN01C-EN
CSC and IntelliPak CSC
Interfaces for the commercial self-contained (CSC) and IntelliPak CSC
provide communication link between each CSC and the BCU. There are
multiple generations of CSC UCMs. The first generation, referred to as
simply CSC, communicates using isolated Comm3. The next generation,
referred to as IntelliPak CSC, is based on the IntelliPak UCM platform. It
communicates on an isolated Comm3 or a Comm4 link using a Tracer
communication interface (TCI), and on a Comm5 link using a LonTalk
communication interface (LCI-I). For specific information about the num-
ber of CSCs allowed per BCU and per communication link, refer to
Table 5 on page 33.
Wiring requirements
For the TCI, attach the communication link wiring to the CSC at TB2-1
(TB2-1 is a terminal block located in the CSC control panel). Attach the
the communication link wiring to the Intellipak CSC at the communica-
tion link + and – terminals. For more detailed information on wiring the
CSC and the Intellipak CSC, refer to product information.
Device addressing
Each UCM on a Comm3 or Comm4 link must have a unique address that
is set using a DIP switch on the CSC. For CSC address DIP switch set-
tings, refer to Table 10 on page 61.
Each UCM on a Comm5 link has a Neuron ID that provides a unique
address.
20 OFF OFF on OFF on
21 on OFF on OFF on
22 OFF on on OFF on
23 on on on OFF on
24 OFF OFF OFF on on
25 on OFF OFF on on
26 OFF on OFF on on
27 on on OFF on on
28 OFF OFF on on on
29 on OFF on on on
30 OFF on on on on
31 on on on on on
32 OFF OFF OFF OFF OFF
Table 9. CCP II DIP switch settings (Continued)
UCM address
CCP II
S2 DIP switch settings
1 2 3 4 5
