Description of UCM types
BMTX-SVN01C-EN 61
For IntelliPak CSCs, addresses are set from the front panel. Refer to the
IntelliPak CSC installation, operation, and maintenance manual for
details.
Table 10. CSC UCM address settings for Comm3 or Comm4
UCM address
CSC Board A5 DIP switch settings
SW6-1 SW6-2 SW6-3 SW6-4 SW6-5
01 OFF OFF OFF OFF on
02 OFF OFF OFF on OFF
03 OFF OFF OFF on on
04 OFF OFF on OFF OFF
05 OFF OFF on OFF on
06 OFF OFF on on OFF
07 OFF OFF on on on
08 OFF on OFF OFF OFF
09 OFF on OFF OFF on
10 OFF on OFF on OFF
11 O F F o n O F F o n o n
12 OFF on on OFF OFF
13 OFF on on OFF on
14 OFF on on on OFF
15 OFF on on on on
16 on OFF OFF OFF OFF
17 on OFF OFF OFF on
18 on OFF OFF on OFF
19 on OFF OFF on on
20 on OFF on OFF OFF
21 on OFF on OFF on
22 on OFF on on OFF
23 on OFF on on on
24 on on OFF OFF OFF
25 on on OFF OFF on
26 on on OFF on OFF
27 on on OFF on on
28 on on on OFF OFF
29 on on on OFF on
30 on on on on OFF
31 on on on on on
