BMTX-SVN01C-EN 55
Chapter 6
UCMs supported by Tracer
Summit systems
UCMs supported by Tracer Summit systems communicate on one, or
more, of the following link types:
• Isolated Comm3
• Comm4
• Comm5
Isolated Comm3 UCMs
The UCMs in the following list communicate with BCUs using the iso-
lated Comm3 communication link. For specific information about the
number of each of these types of UCMs allowed per BCU and per commu-
nication link, refer to Table 5 on page 33.
• Central control panel (CCP)
• Commercial self-contained (CSC)
• Intellipak
• IntelliPak CSC
• Lighting control panel (LCP)
• Programmable control module (PCM)
• RTA-RTW chiller interface
• Scroll chiller (CGA/CGW/CGAF) interfaces
• Thermostat Control Module (TCM)
• Trane Europe chiller interface
• Voyager rooftop unit interface
Wiring requirements
To establish wiring connections between UCM and the BMTX BCU, refer
to the specifications on wire type, topology, and wiring procedures in “” on
page 34. For UCM connection points, refer to literature for the specific
UCM.
UCM addresses
UCMs that communicate using isolated Comm3 need to have addresses
set with DIP switches or local displays. Tables with address settings and
DIP switch settings are provided for some of the UCMs in this chapter. As
an alternative, refer to Appendix A for a table that can be used for all DIP
switch settings.
