Chapter 1 Tracer Summit system overview
8 BMTX-SVN01C-EN
BMTX BCU parts list
Table 1 gives a complete list of BMTX BCU parts by item number.
Figure 3 on page 9 illustrates each part, showing corresponding item
numbers. Table 2 describes how to use a model number for ordering a
BMTX BCU.
Table 1. BMTX BCU parts list
Item
Model # digit(s)
Model # options
Design revision
SVC parts mnemonic #
Service parts, GCC ordering
GCC part #
Description
1 13 1 A0 MOD01524 S3090-0525-62 50100922 BMTX main logic board,
with modem
(item 8 is included with this
part)
2 13 0 A0 MOD01491 S3090-0510-62 50100922 BMTX main logic board,
without modem
(item 8 is included with this
part)
3 13 1 A0 BRD02957 S3090-0409-62 41513058 On-board modem
(Also available as part of
item 1)
4 12 1 A0 CAB00990 S3090-0321-62 35914305 Cable for operator display
5 12 0 A0 COV03554 S3090-0484-62 31801008-B Cover, without operator
display
6 12 1 A0 COV03553 S3090-0483-62 40201224 Cover, with operator display
and cable
7 All models N/A A0 COV03311 S3090-0309-62 31800896-R02 Power wiring cover
8 All models N/A A0 PNL14797 S3090-0319-62 31800902-R02 Carrier for main logic board
9 All models N/A A0 MOD01411 S3090-0408-62 50100923 plus
318000903
Termination board with
lower carriage
10 All models N/A A0 PNL14789 S3090-0329-62 31800885-R03 Metal enclosure base
11 8 A A0 TRR01279 S3090-0429-62 35805010-R03 Transformer, 120/240 Vac,
24 Vac, 76 VA
12 8 B A0 TRR01788 S3090-0493-62 35806022-R01 Transformer, 230 Vac
13 All models N/A A0 BLK01013 S3090-0415-62 35601131 Two-pole terminal block
