BMTX-SVN01C-EN 135
Index
A
AH540/541, see Tracer AH540/541
ARCNET
BACnet/IP router, 103
connecting to Ethernet, 96
network communication, 89
not supported by BMTX BCU, 96
B
BACnet
communication over LANs, 89
configuring a compatible device, 98
definition of, 129
device IDs, need for unique, 89
BACnet/IP communication, 109
BACnet/IP router, 103
BCU
addressing, 89
clear code, database, RAM, and reset
procedure, 121
clear Comm5 database, 122
clear database, RAM, and reset
procedure, 121
clear RAM and reset procedure, 120
clearances, 19
communication link locations, 34
communication protocol, 5
components of, 3–4
configuring for BACnet/IP, 109
definition of, 129
device address, 89
device ID, 89
dimensions, 18
DIP switch settings, 90
model number, 10
modem,
see BCU modem
mounting, 20
operating environment, 17
operation status, 115, 118
reset procedures, 120
selecting a mounting location, 17
seven-segment LED display codes,
115, 118
startup sequence for new, 119
startup sequence for programmed,
119
storage temperature of panel, 7
troubleshooting, 125–128
UCM communication with, types and
quantities, 33
BCU modem
installing, 13
requirements, 5
binary inputs
binary devices supported, 27
check-out procedure, 29
wiring, 27
wiring location and procedure, 28
BMTX BCU,
see BCU
branch configuration, 38
broadcast distribution table (BDT), 102
C
CCP
addressing, 59
description, 58
wiring, 59
CCP, definition of, 129
check-out procedures for binary inputs,
29
clearances for BCU, 19
code, definition of, 129
Comm3
best wiring practices, 35
branch configuration, 38
configuration requirements, 35
daisy-chain configuration, 37
fiber-optic modems, 39
fiber-optic wiring, 39
resistance termination, 39
wiring, 34, 35
wiring overview, 35
wiring procedure, 36
Comm3 UCMs
addresses, 55
CSC, 60
IntelliPak CSC, 60
IntelliPak RTU, 64
LCP, 65
PCM, 70
RTA-RTW, 71
scroll chillers, 72
Trane Europe chiller, 77
Voyager RTU, 85
wiring, 55
Comm4
best wiring practices, 35
branch configuration, 38
