Comm5 UCMs
BMTX-SVN01C-EN 57
Neuron ID
Each Comm5 UCM or LonTalk
®
device is assigned a unique identification
number called a Neuron ID. The Neuron ID replaces the UCM addresses
used for Comm3 and Comm4. The Neuron ID is typically printed on a
label located on the logic board of each UCM. You can view the Neuron ID
from Tracer Summit when communication is established. (For more infor-
mation, refer to the Tracer Summit Programming guide.)
Table 8. Comm5 UCMs and corresponding Tracer Summit object type
Object type Comm5 UCMs
Control mode
configuration
1,2
Chiller LCI-C (Version 16 and higher)
N/A
Discharge Air Controller (DAC) LCI-R (Voyager 3) N/A
LCI-I, IntelliPak Commercial Self-Contained (CSC) VAV
LCI-I, IntelliPak—Fresh Air Unit (FAU) Constant volume
LCI-I, IntelliPak—Roof Top Unit (RTU) VAV
Tracer AH540/541 Discharge air tempera-
ture
Generic LonTalk Device (GLD) Tracer MP501 (configured as generic: temperature,
pressure, flow, percent of parts per million)
Generic: temperature,
pressure, flow, per-
cent of ppm
Tracer MP503 I/O module N/A
LCI-C (before Version 16) N/A
Other LonTalk devices such as meters, variable fre-
quency drives, sensors, actuators
N/A
MP580/581 Tracer MP580/581 Space temperature
Tracer MP580/581 Discharge air tempera-
ture
Tracer MP580/581 Generic
Space Comfort Controller
(SCC)
LCI-R (Voyager 3, Voyager 2, Precedent) N/A
LCI-V N/A
LCI-I, IntelliPak - Commercial Self-Contained (CSC) Constant volume
Tracer AH540/541 Space temperature
Tracer MP501 Space temperature
Tracer VV550/551 N/A
Tracer ZN510/511 N/A
Tracer ZN517 N/A
Tracer ZN520/521 N/A
Tracer ZN524 N/A
Tracer Loop Controller (TLC) Tracer Loop Controller (TLC) N/A
1
Configure the control mode of UCMs, either at the factory or in the field, using the Rover service tool. Configure the unit type of
some UCMs, such as the Tracer CH530/531, using the TechView or another service tool.
2 N/A = Control mode does not affect the object type.
