Chapter 7 Network communication
90 BMTX-SVN01C-EN
Ethernet communication
To operate on an Ethernet network, each Tracer Summit PC Workstation
must have an Ethernet network interface card installed in it. Different
BCU models can exist on the same Ethernet network (see “IP networks”
on page 96 for specific limitations). The Tracer Summit software version
that is required depends on the newest model of BCU that is on the net-
work:
• A network with a BMTS BCU must be running Version 5 or higher.
• A network with a BMTW BCU must be running Version 11 or higher.
• A network with a BMTX BCU must be running Version 16 or higher.
Table 25. BCU device ID: DIP switch settings
Device ID
DIP switch number
S2-1 S2-2 S2-3 S2-4 S2-5 S2-6 S2-7 S2-8
01 OFFononononononon
02 onOFFonononononon
03 OFF OFF on on on on on on
04 on on OFF on on on on on
05 OFF on OFF on on on on on
06 on OFF OFF on on on on on
07 OFF OFF OFF on on on on on
08 on on on OFF on on on on
09 OFF on on OFF on on on on
10 on OFF on OFF on on on on
11 OFF OFF on OFF on on on on
12 on on OFF OFF on on on on
13 OFF on OFF OFF on on on on
14 on OFF OFF OFF on on on on
15 OFF OFF OFF OFF on on on on
16 on on on on OFF on on on
255 OFF OFF OFF OFF OFF OFF OFF OFF
Note:
• The device ID can be set from 1 to 254 using the DIP switch or 1 to 4194303 when softset. To softset the address on a BCU, set
the DIP switch to 255 (all OFF), then use the IP Validation utility to edit the desired address.
• Cycle system power to reset the device ID configuration.
