Appendix
Specicaons
Item Specicaons
Chipset Qualcomm QCA9563+QCA9882
Standards • EEE 802.11b/g/n Wireless LAN 2.4GHz
• IEEE 802.11a/n/ac Wireless LAN 5GHz
• IEEE 802.3/IEEE 802.3z Gigabit Ethernet
• IEEE 802.3at PoE
• ANSI/IEEE 802.3 Auto negoaon
Radio Technology • IEEE 802.11g / IEEE 802.11n / IEEE 802.11a/n/ac
Orthogonal Frequency Division Mulplexing (OFDM)
• IEEE 802.11b: Direct Sequence Spread Spectrum (DSSS)
Transmission Rate • 802.11ac: up to 867Mbps
• 802.11an: up to 300Mbps
• 802.11a: up to 54Mbps
• 802.11n: up to 300Mbps
• 802.11g: up to 54Mbps
• 802.11b: up to 11Mbps
Receiver Sensivity • 11ac VHT80 MCS9: Typical - 51dBm @ 10% PER
• 11ac VHT40 MCS9: Typical - 54dBm @ 10% PER
• 11ac VHT20 MCS9: Typical - 57dBm @ 10% PER
• 11a/n HT40 MCS7/15/23: Typical - 61dBm @ 10% PER
• 11a/n HT20 MCS7/15/23: Typical - 64dBm @ 10% PER
• 11a/g 54Mbps: Typical - 65dBm @ 10% PER
• 11b 11Mbps: Typical - 83dBm @ 8% PER
Frequency • 2.4GHz: 2412 ~ 2472 MHz ISM band (channels 1 ~ 13)
• 5GHz: 5180 ~ 5825 MHz ISM band (channels 36 ~ 165)
Wireless Channel • 2.4GHz: Channel 1 ~ 11(FCC), Channel 1 ~ 13(ETSI)
• 5 GHz: 36, 40, 44, 48, 149, 153, 157, 161 and 165 (FCC),
36, 40, 44, 48(ETSI)
Modulaon • DBPSK/DQPSK/CCK for DSSS technique
• BPSK/QPSK/16-QAM/64-QAM/256-QAM for OFDM
technique
Item Specicaons
Media Access Protocol CSMA/CA with ACK
Wireless Output Power/
Receiving Sensivity (per
chain)
2.4G Mode
• FCC:23dBm, ETSI:10dBm (max) @ 802.11b
• FCC:19dBm, ETSI:12Bm (max) @ 802.11g
• FCC:19dBm, ETSI:12dBm (max) @ 802.11n HT20
• FCC:19dBm, ETSI:12dBm (max) @ 802.11n HT40
5G Mode
• FCC:24dBm, ETSI:22dBm (max) @ 802.11a
• FCC:24dBm, ETSI:22dBm (max) @ 802.11n HT20 /
802.11ac VHT20
• FCC:15dBm, ETSI:22dBm (max) @ 802.11ac VHT80
Antenna Type • 2.4 GHz: 2 x 4dBi (Peak) PIFA Antenna’s internal
• 5 GHz: 2 x 4dBi (Peak) PIFA Antenna’s internal
Antenna Gain • 2.4 GHz: 2 dBi (max.) / 0 dBi (Avg.) internal
• 5 GHz: 2 dBi (max.) / 0 dBi (Avg.) internal
Protocol TCP/IP
Hardware Interface • LAN: 1 x 10/100/1000Mbps Auto-MDIX Gigabit
Ethernet port
• Reset buon
• Power Jack
Operaon Modes • Access Point (AP), AP+WDS
SSID Up to 4 SSIDs per band (AP mode)
Supported Network
Protocols
• TCP/IP
• HTTP
DHCP Server/Client
Network Management
Web base conguraon ulity via Ethernet
Channel • 2.4GHz: Channel 1 ~ 11(FCC), Channel 1 ~ 13(ETSI)
• 5 GHz: 36, 40, 44, 48, 149, 153, 157, 161 and 165 (FCC),
36, 40, 44, 48(ETSI)
Security • 64/128-bits WEP Encrypon
• WPA, WPA2
• WPA-PSK, WPA2-PSK
• MAC address ltering
