Triumph Rocket 3 R User Manual

Instruments
33
Warning
If traction control has been disabled in
the Main Menu as described on page 46
then settings saved for all riding
modes will be overridden.
Traction control will remain off
regardless of your riding mode
selection until re-enabled, or the
ignition has been switched off then
on again, or the MODE button is
held in to return to the default Road
mode (which enables the traction
control when the motorcycle is next
stationary).
If the traction control is disabled,
the motorcycle will handle as normal
but without traction control. In this
situation accelerating too hard on
wet/slippery road surfaces may cause
the rear wheel to slip, and may result
in loss of motorcycle control and an
accident.
Warning
If the ABS is disabled, the brake
system will function as a non-ABS
equipped braking system. In this
situation braking too hard will cause
the wheels to lock, and may result
in loss of motorcycle control and an
accident.
Warning
After selecting a riding mode, operate
the motorcycle in an area free from
traffic to gain familiarity with the new
settings.
Do not loan your motorcycle to anyone
as they may change the riding mode
settings from the one you are familiar
with, causing loss of motorcycle
control and an accident.
To select a riding mode:
•
Press and release the MODE button
on the left hand switch housing to
activate the riding mode information
tray and riding mode selection
panel.
•
The currently active riding mode
icon is shown in the center of the
instrument panel.
To change the selected riding mode:
•
Either push the joystick left or
right, or repeatedly press the MODE
button until the required mode is
shown in the center of the display
screen or highlighted in the riding
mode selection panel.

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
