Output Project
The Output Project function within the Projects menu allows the
operator to print or upload project data stored in the gauge to a
computer or serial printer connected to the serial port, to a USB
printer or storage device connected to the USB port, or to a
Bluetooth enabled device. To select the output destination, see
page 8–9.
Uploading or Printing Project Data
Uploading Data Using the Serial Port
You can upload project data to a computer via the serial port
using Troxler’s Gauge Download Program, available at:
www.troxlerlabs.com/downloads/software/gaugedownload.zip
You can also upload the data using Windows
®
HyperTerminal or
Terra Term. See the “Downloading Data” procedure at
www.troxlerlabs.com/documents for HyperTerminal instructions.
To output project data via the 9-pin serial port, connect a serial
cable to the port. An optional serial cable, P/N 113128, is
available from Troxler. Connect the serial cable to the
computer’s COM port (or a printer’s serial port).
Uploading or Printing Data Using the USB Port
To output project data to a USB printer via the USB port,
connect a USB cable to the USB port and connect the cable to the
USB printer. To output project data to a USB storage device,
connect the storage device directly to the USB port.
NOTE
The opening for the USB port accepts a device with
maximum dimensions of 10 mm (0.40 in.) high by
29 mm (0.79 in.) wide.
