CHAPTER 2
Unpacking and Setting
Up
2-1
This chapter gives unpacking and setup information for the
Model 3022A Condensation Particle Counter (CPC).
Packing List
Table 2-1 shows the packing list for the Model 3022A CPC.
Table 2-1
Model 3022A CPC Packing List
Qty. Description Part No.
1 CPC sensor 302201
1 Power cable, 110–120V 1303053
220–240V 1303075
1 12 foot 9-pin (M/F) interface cable 962002
1 Cable adapter 25-pin (F) to 9-pin (M) 962003
1 Nylon plug 1601834
1 Inlet tube, side, 2.8 inches 1503450
1 Inlet tube, back, 5.2 inches 1503452
1 Bottle bracket 1503475
2 Screw, 8-32 ×
3
/8, Phillips pan-head 5094090
2 Washer, no. 8 internal tooth 5329031
1 Fill bottle assembly (tested) 1035590
1 Drain bottle assembly (tested) 1035591
1 Filter media for fan 1602071
2 Tube filter 1602061
1 Pump exhaust filter 1602080
1 Instruction manual 1933763
1 Software disk, 3.5-inch format 1905118
Unpacking Instructions
The Condensation Particle Counter comes fully assembled with
protective coverings on the Inlet and Liquid Drain ports and
electrical connections.
To avoid contaminating the instrument or the environment the CPC
is monitoring, do not remove the protective covers until you are
ready to install the instrument.
If anything is missing or appears to be damaged, contact your TSI
representative or contact TSI Customer Service at 1-800-874-2811
(USA) or (651) 490-2811. Chapter 9, “Maintenance and Service,”
gives instructions for returning the CPC to TSI Incorporated.
