TSI Instruments 3022A User Manual

Unpacking and Setting Up 2-5
Jumper Bar
Fuse Block
Cover
Fuse
Figure 2-3
North American–Fusing Arrangement
Fuse Block
Cover
Fuses
Jumper Bar
Figure 2-4
European–Fusing Arrangement
3. Loosen the screw on the fuse block two turns.
4. Remove the fuse block (Figure 2-5) by sliding it up and away
from the screw. Lift the block from the pedestal.
Fuse
Fuse Block
Cover
Figure 2-5
Fuse Block/Cover Assembly
