4-2 Model 3022A Condensation Particle Counter
3. Move the red paddle switch to the far right position (Figure 4-2).
Display PC Board
Disable
Enable
Configuration Switch (Red)
Figure 4-2
Setting the Configuration Switch to Enable the Configuration Mode
4. Run the configuration sequence (see “Running the Configuration
Function” in this chapter). Be sure the CPC is fully warmed-up
before resetting any calibration points.
5. After configuring the CPC, it is a good idea to set the switch back
to the disable position to prevent tampering.
6. Replace the top cover.
