4-4 Model 3022A Condensation Particle Counter
Question Answer Explanation
Must fill? Y
N
Yes: A yes requires that the liquid reservoir be
full for concentration display.
No (default)
Total? 20s
60s
200s
600s
2000s
6000s
9999s
No Lmt
Second for total; when the time has elapsed,
the counting stops.
No limit (default)
Output? E1
E2
E3
E4
E5
E6
E7
0 to 10 particles/cm
3
0 to 100 particles/cm
3
0 to 1000 particles/cm
3
0 to 10,000 particles/cm
3
0 to 100,000 particles/cm
3
0 to 1,000,000 particles/cm
3
0 to 10,000,000 particles/cm
3
LOG Logarithmic concentration output; 0 to
10,000,000 particles/cm
3
(0 to 10 volts log: 10 volts = 10,000,000
particles/cm
3
9 = 1,000,000
8 = 100,000
7 = 10,000
6 = 1,000
5 = 100
4 = 10
3 = 1
2 = 0.1
1 = 0.01
0 = ≤0.001)
FLOW Flow in units of cm
3
/s as measured by the
volumetric flowmeter; 1 volt = 1 cm
3
/s
PUMP 0 to 10 volts, microprocessor control range (0
to 255 percent) to the pump. 0 volts represents
1.55 volts to the pump; 10 volts represents 12
volts to the pump. Pump voltage = P (12) + (1-
P) (1.55) where P = pump.
HOST 0-11 volt signal that can be set by a [HOST]
computer via the RS-232 port. This mode is
useful when controlling an instrument such as
the Electrostatic Classifier with the 3022A CPC
as part of a DMPS or SMPS system.
continued
