2–4 Series 3080 Electrostatic Classifiers
50-60 Hz, 200 W max., single phase. The connector has a built-in
on/off switch.
Notes: Make certain the line cord is plugged into a grounded (earth
grounded) power outlet. Position the Classifier so the power
cord connector is not blocked and is easily accessible.
The Classifier power supply contains no user-serviceable
parts. If the power supply is not operating correctly, use the
information in Chapter 6, “Technical Contacts”
to contact TSI.
This instrument should not be used in a manner not specified
by the manufacturer.
Toggle the on/off switch at the AC POWER IN connection on the
back panel to the on position to verify the instrument has power.
Alternately, connect 24 VDC to the DC POWER IN connection.
Contact TSI to order the necessary connector (TSI part number
1035551).
Analog Input
There is an Analog Input connector on the Classifier (located just
below the Serial Port on the back panel) for analog control of the
High-Voltage supplied to the DMA. Usually, this is used for input of
the control signal from a Condensation Particle Counter in a
Scanning Mobility Particle Sizer
TM
(SMPS
TM
) system.
Connecting a Computer
Although normally only necessary for instrument calibration at the
factory, it is possible to communicate directly with the Classifier
using a computer. Refer to Appendix C
for detailed information on
communicating with the instrument.
Installing the Kr-85 Bipolar Charger
The Kr-85 neutralizer is shipped separately because of regulations
that govern packaging requirements for radioactive materials.
