C–2 Series 3080 Electrostatic Classifiers

5 4 3 2 1

9 8 7 6

Figure C-1

Serial Port Pin Designations

Table C-1

Signal Connections for RS-232 Configurations

Pin Number RS-232 Signal

1 —

2 Transmit Output

3 Receive Input

4 —

5 GND

6 —

7 —

8 —

9 —

Figure C-2

Serial Port Connector on the Back of the Classifier
