D-10 Series 3080 Electrostatic Classifiers
13. Repeat steps 6 to 12 for the 0.0508 and 0.071 cm nozzles by
selecting those sizes from the Impactor Nozzle Type drop-
down box.
14. The calibration file can be saved by pressing the Save button;
But saving the file is not required for this calibration
procedure.
15. Exit the Sheath Calibration Screen on the Classifier and close
the software window.
Working with Calibration Files
In the calibration screen there are four buttons that are used to
work with the calibration files: Set Calibration, Save, Load, and
Print. The buttons are used as follows:
Use the Set Calibration button to send the
calibration settings to the Classifier as
discussed previously in this appendix.
Use the Save button to write out all of the
calibration values for the Sheath, Bypass
or Impactor flows into a file.
Use the Load button to load a previously
saved calibration from a file into the
program.
Use the Print button to print the
calibration tables on a single page, in
landscape mode.
