A-2 Series 3080 Electrostatic Classifiers
Table A-2
Specifications of the 3080 Controller Platform (continued)
Environmental Conditions
Indoor use
Altitude up to 3000 m (10,000 ft)
Ambient temperature 10°-40°C
Ambient humidity 0-90% RH non-
condensing
Over-voltage category II
Pollution degree II
Table A-3
Specifications of the 3080L Electrostatic Classifier
DMA included
Long (Model 3081)
Particle type
Solids and nonvolatile liquids
Particle size range (generation
mode)
Adjustable from 10 to 1000 nm
Maximum input concentration
10
8
particles/cm
3
at 10 nm
Voltage
10 to 10,000 VDC
Flow rates
Sheath air 2 to 15 L/min (Dual Blower mode)
Aerosol 0.2 to 1.5 L/min
Bypass None
Physical measurements
Long DMA
Height 61 cm (24 in.)
Outside diameter 7.6 cm (3 in.) excluding ports
Weight 5.4 kg (11.8 lb)
Monodisperse and polydisperse
aerosol ports
¼-in. OD
Sheath and excess air ports
3
⁄8-in. OD
Complete instrument
Dimensions (LWH)
45.7 cm × 41.4 cm × 64.3 cm
(18 in. × 16.3 in. × 25.3 in.)
Weight 23.2 kg (51.2 lbs)
