Unpacking and Setting up the System 2–17
6. Connect tube #4 from the Classifier port marked EXHAUST
FLOW to the Classifier port marked EXCESS FLOW.
7. In this setup, the bypass flow is not used. Add the cap to the
DMA port marked BYPASS FLOW.
Table 2-5
Tubing Connections for Model 3085 Nano DMA in Dual Blower mode
Tube # Length Description Part No.
1 8-in [203-mm] Black, fits
1
⁄4-in [6.35-mm] fitting 3001903
2 7-in [178-mm] Black, fits
3
⁄8-in [9.5-mm] fitting 3001904
3 9.5-in [241-mm] Black, fits
3
⁄8-in [9.5-mm] fitting 3001904
4 6.5-in [165-mm] Black, fits
3
⁄8-in [9.5-mm] fitting 3001904
5
3
⁄8 to ¼-in tubing adapter 1035992
6
3
⁄8-in cap fitting 1611270
High-Voltage Connection
Each DMA has a high-voltage cable and connector specially
designed to connect to the Electrostatic Classifier cabinet.
Caution
You should never pull or tug on the high-voltage cable—always grip the
plug to disconnect the cable. You should never use the cable to carry or
move the instrument. If the cable breaks, you could be exposed to
dangerous high voltage. A cut or damaged cable should be replaced
immediately. Always switch the instrument off before connecting or
disconnecting the high-voltage connector.
1. When the Long or Nano DMA is secure, plug the high-voltage
cord into the socket marked: HIGH VOLTAGE OUT FOR DMA
ONLY on the side of the Classifier. The connector simply pushes
together.
2. To remove the high-voltage connector, grip the connector and
pull straight out.
