2–1
CHAPTER 2
Unpacking and Setting
Up the System
Use the information in this chapter to unpack and setup the
Model 3080 Electrostatic Classifier.
Packing List
As you unpack the shipping container, make certain the shipment
is complete. Table 2-1 gives a packing list for the Classifier.
Table 2-1
Classifier Packing List
Qty Description Part No.
1 Model 3080 Electrostatic Classifier 3080
1 Electrostatic Classifier Accessory Kit Including:
1 Support Bracket for Long DMA w/screws 1035991
1 Fitting Adapter,
3
⁄8 to ¼ 1035992
1
3
⁄8-in cap fitting 1611270
1 Cable, Power Supply
1 Cable, RS-232 Serial 962002
1 Serial Cable Adapter, 25F to 9M 962003
1 3080 Manual 1933792
10 ft [3.0 m] Tubing, Silicone Conductive, fits ¼-in barb
fitting (
3
⁄8-in OD × 0.19-in ID) 3001903
10 ft [3.0 m] Tubing, Silicone Conductive, fits
3
⁄8-in barb
fitting (½-in OD × 0.31-in ID) 3001904
10 ft [3.0 m] Tubing, Tygon Clear ¼-in OD ×
3
⁄8-in ID 3001220
Unpacking Instructions
The Model 3080 is not shipped fully assembled. A Model 3077A (or
the optional Model 3077) Aerosol Neutralizer must be installed for
the Classifier to operate properly. Use the instructions given later in
this chapter to install the Neutralizer. If you ordered the Model
3080 with a DMA, the DMA must be installed and properly
plumbed. See the sections later in this chapter for instructions.
