D301087 0308 - BL20 CANopen 1-9
BL20 Components
1
Base Modules
The field wiring is connected to the base modules. These are
constructed as terminals in block and slice designs and are available
in the following variations with either tension clamp or screw
connections: 2-/3-wire (2-channel), 4-wire (2-channel) and 4x 2-/3-
wire (4-channel).
The assignment table in the Section "Ordering Information" of the
"Appendix" shows the possible combinations of electronics and
base modules.
Figure 6:
Base module with
tension clamp
connection
