turck BL20 - Digital Output Modules

Diagnostics - Emergency Frames
D301087 0308 - BL20 CANopen5-10
Digital Output Modules
Designation/
Meaning
Byte 0/1
Error code
Byte 2
Error register
Byte 3
Extra info
Byte 4
Extra info
Load dumps
at outputs:
Open circuit or
current too low
(threshold: posi-
tive converter
limit value)
2310
hex
Bit 1 = 1
(current error)
Module
number
Channel number
Output
current out of
range:
The current is
outside of the
permissible
range
A
2330
hex
Bit 1 = 1
(current error)
Module
number
Channel number
Note
For the exact byte assignment of the Emergency frame, please see
"Structure of the Emergency Frames", page 5-3.
