BL20 - Gateway for CANopen
D301087 0308 - BL20 CANopen3-10
Base Modules
Table 3:
Technical data for
base modules
Protection class IP 20
Measurement data according to VDE 0611 Part 1/8.92/
IEC 947-7-1/1989
Insulation stripping length 8 mm / 0.32 inch
Max. wire range 0.5 to 2.5 mm
2
/ 0.0008 to
0.0039 inch
2
/ 20 to 12 AWG
Crimpable wire
"e” solid core H 07V-U 0.5 to 2.5 mm
2
/ 0.0008 to
0.0039 inch
2
/ 20 to 12 AWG
"f” flexible core H 07V-K 0.5 to 1.5 mm
2
/ 0.0008 to
0.0023 inch
2
/ 20 to 16 AWG
"f” with ferrules according to
DIN 46228/1 (ferrules crimped
gas-tight)
0.5 to 1.5 mm
2
/ 0.0008 to
0.0023 inch
2
/ 20 to 16 AWG
Plug gauge according to
IEC 947-1/1988
A1
TOP connection technology Tension clamp or screw
connection
